The electrospinning technique is a simple and elegant method to produce nanofibers. In , Formhals patented a process to produce polymer filaments using electrostatic force. Later on, the process evolved and was named as electrospinning [ 79 — 81 ]. So far, hundreds of polymers have been successfully fabricated by electrospinning process [ 87 ]. The basic schematic setup for the electrospinning process is shown in Figure A basic electrospinning setup [ 88 ].

In the electrospinning process a charged liquid polymer solution is introduced into an electric field. After that it is deposited on a collector which is grounded. The cathode of the HV power supply is attached to a wire and inserted into the syringe containing the polymer solution and the anode is attached to the ground.

A rotating drum, usually wrapped with aluminum foil can be used as a collector. The inner diameter of a needle can be between 0. The ejected polymer solution forms a continuous nanofiber when the high voltage overcomes the surface tension. Once the ejection starts, at the tip of the needle, the pendant droplet of the polymer solution forms a conical shape, typically referred to as Taylor cone.

Whilst the fluid is charged, the surface charge and the surface tension operate in opposite relation. Therefore, the fluid changes shape and the formed structure is known as the Taylor cone [ 89 ]. The images of the formation of a Taylor cone are shown in Figure The key parameters which affect the formation of nanofibers are 1 solution parameters such as viscosity, conductivity, surface tension, and vapor pressure; 2 process parameters such as shape of collector, needle diameter, solution flow rate, tip to collector distance, and applied voltage; 3 ambient parameters such as solution temperature, humidity, and air velocity in the electrospinning chamber.

By varying these parameters the thickness and smoothness of the fibers can be controlled [ 90 ]. SEM micrographs of a polypyrrole electrospun nanofibers, formed from aqueous solutions of 1. The polypyrrole content of the nanofibers is Recently the inkjet printing approach has been adopted for fabrication of electronics devices, where the colored ink cartridge is replaced with a functional electronic ink, for example, semiconducting ink and conductive ink.

Today, inkjet printing is used in electronic industries and research for fabrication of printed circuit boards PCB , light-emitting diodes LED , thin film transistors TFT , solar cells, thermoelectric devices, and many others [ 91 — 96 ]. With that being said, inkjet printing is an attractive method to be used in the fabrication of the whole or part of the structure of thermoelectric devices. Traditionally, thermoelectric devices structure is produced by conventional printing such as lithography and roll-to-roll printing [ 97 ].

Conventional methods require series of processes flow such as etching, cleaning, and dicing, which is time consuming and produces a lot of waste material [ 91 ]. With the ability to accurately deposit minute amounts of materials onto substrate, inkjet printing provides the alternative for fabrication of thermoelectric devices. A schematic of the operation of the inkjet printer is shown in Figure Ink is deposited onto substrate to fabricate multiple layers structure.

Step by step process for fabrication of device using inkjet printing [ 98 ]. The field of printable electronics is becoming more significant. This technology requires the active electronic materials, such as metals, organometallics, nanoparticles, and biopolymers in solution form, and thus soluble organic or polymeric materials are attractive candidates for this processing method.
